Natural flake graphite is added to refractories to improve performance. Refractories are used to line furnaces and vessels to support high-temperature processing across a wide range of industries, including iron and steel production(Steel ladels and Electric arc furnaces -EAF), Basic oxygen furnace (BOF), non-ferrous metals, cement and lime, glass, and chemicals.
▼Product Decription:
Natural Flake graphite powder and Flake in Refractories industry.
Natural graphite has extensively used in refractoies to improve the performance and service life for your products. In all ages, and old version and modern refractory products and, Xingshi Natural Flake graphite is a vital component and prime choice for your production.
▼ Natural Flake graphite Charracteristics and Size in Refractories
High carbon graphite （ Coarse Natural flake graphite - Fine grain size 50-200mesh)
| Xingshi Item | +599 | +899 | +199 | -198 | ±197 |
C % ≥ | 99 | 99 | 99 | 98 | 97 |
VM % ≤ | 1.0 | 1.0 | 1.0 | 1.0 | 1.2 |
Moisture % ≤ | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Grain Size(mesh) | +50 Mesh(300μm）≥ 80% | +80 Mesh（180μm） ≥ 80% | +100 Mesh（150μm） ≥ 80% | +100 Mesh≤ 20% -100 Mesh≥ 80% | +100 Mesh≤ 20% -100 Mesh≥ 80% |
| Brand Item | +196 | -196 | ±194 | +895 | -297 |
C % ≥ | 96 | 96 | 96 | 95 | 97 |
VM % ≤ | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
Moisture % ≤ | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Grain Size(mesh) |
| +100 Mesh≥ 80% | +100 Mesh≤ 20% -100 Mesh≥ 80% | +80 Mesh≥ 80% | +200 Mesh≤ 20% -200 Mesh≥ 80% |
▼ Xingshi Natural Flake graphite Advantage
1. Thermal Shock Resistance: Xingshi Natural flake graphite has a high thermal conductivity, when added to refractoriues, the internal thermal gradient between the hot and cold materials is considerably reduced, thus effectively decreasing internal stresses and improving thermal shock and spalling resistance.
2. Corrosion resistnace: Xingshi Natural flake graphite is not wetted by molten slag, When present in the refractory, Xingshi natural graphite prevents penetration of slag and molten metal through the crack network inside the refractory, that effectively improves corrosion resistance .
3. Oxidation Resistance: Xingshi Natural flake graphite, Larger and purer flakes are therefore more resistance with larger size. our natural graphite shows excellent resistance to oxidation, and this translates into longer refractory life.
OTHERS - Outstanding resistance to chemical attacks
- Stability over a wide range of temperature with very low thermal expansion coefficient.
- Reduced tool wear during pressing because it unique lubricant action of the natural graphite
- Malleable and very easy to model into shape.
Our speciallists will be gald to help you in the selection of the most suitable product as per your application. Depending on customer requirements our products are delivered in 25 kg bags in Jumbo bag, For details , Feel free to contact us via Contact Us
